Paper Bursting Strength Tester For Carton Box UI-P03
Description
Paper bursting strength tester is used to test bursting strength of paper, corrugated box, carton box, paper board and etc. This burst strength tester is a universal digital bursting strength tester which can be used to test fabric, leather, silk and etc.
1. Which equipment was used to measure the bursting strength of paper?
Burst Strength Tester(BST) is used to measure the bursting strength of paper.
Unuo Instruments supplies various kinds of bursting strength testers according to different kinds of materials and test methods. Find more Burst strength testers here and Get A Quote Today.
2. Paper Bursting Machine Principle
This machine is a hydraulic bursting strength tester, uses advanced microcomputer detection control system and digital signal processing technology to measure the bursting strength of paper, cardboard, and automatically retains the maximum bursting strength value when the sample is broken.
3. How To Test The Bursting Strength Of Paper?
Place the test piece on the film, and then apply pressure evenly, so that the sample and the film can protrude freely until the sample breaks. The maximum value of the applied air pressure is the value of the bursting strength of the test piece.
4. What is the standard for bursting strength tester?
JIS-L1004, L1018, L1031, K6328, P8131, P8112, ASTM-D2210, TAPPI T403, ISO2759-2001, GB/T1539
5. Bursting Strength Tester Specifications
- Sensing method: pressure converter
- Instruction mode: touch screen control
- Operation mode: fully automatic
- Force unit: kpa, psi (Lbs/in^2), kgf/cm^2, with unit switching function
- Burst resistance measurement range: 0-100kg/cm2
- Measurement accuracy: 0.5 kg/cm2
- Clamp ring inner diameter: upper and lower clamp ring inner diameter φ5±0.25mm
- Hydraulic oil: glycerin 85%, distilled water 15%
- Pressurization speed: high pressure type 170±10ml/min
- Accuracy: ±5%
- Automatic clamping and releasing device, specimen clamping force: >690kpa
- Dimensions: (L×W×H)450×4250×520mm
- Machine weight: 60kg
- Power: 120W
- Power supply: 1∮AC220±10%, 50Hz
- Accessories: 10 pieces of correction sheet, 2 pieces of rubber film
