Color Matching Booth UI-TX03

Color Matching Booth is used to assess color difference under different light sources.

  • Unuo Instruments
  • 18 months warranty
  • Fast Delivery
  • ASTM D1729, ISO 3664 and etc
Get A Quote Today


Color Matching Booth is used to assess color difference under different light sources. Color Viewing Light Box is widely used in textiles, toys, dyeing, plastics, paints, inks, printing, pigments, chemicals, footwear, leather, cosmetics, etc. and other color industries for goods color deviation.

Unuo is Colour Matching Cabinet Manufacturer and supplies it in affordable price. Unuo colour matching cabinet meets standard of ASTM D1729, ISO 3664 and etc. Find more color fastness tester here to complete your test!

Principle: Different color would appear on test samples due to the different energy radiant of different light sources. Usually, colour matching cabinet would have TL84 light source, D65, UV, F/A, CWF, U30. More light sources like D50, U35, TL83 and etc are available. Operator may assess the color difference by switching the light sources.

1. Unuo Color Matching Booth Features:

  • Multi light sources for choose;
  • Different booth size for choose;
  • 45° viewing table provided;
Model UI-TX03
Sub-Model TX03A TX03B TX03C TX03D
Light Sources 4



(D65,TL84,UV,F, CWF)


(D65,TL84,UV,F, CWF,U30)


(D65,TL84,UV,F, CWF, U30, A)

Lamp Length 600mm or 1200mm

2. Light Sources Details

Light Source Color Temperature Power
D65 6500K 18W
TL84 4000K 18W
UV 20W
F 2700K 18W
CWF 4200K 40W
U30 3000K 18W
A 2856K 60W

3. Color Viewing Light Box Use Tips

  1.  Viewing Angle
    -Method A: 45° viewing
    Place the sample on the bottom plate of chamber, and view the sample in 45°            -Method B: 0° viewing
    Place the sample on 45 fixed angle table, view the sample in 0°. That means viewing sample vertical with light.
  2. Sample Position In The Chamber
    No matter which viewing methods mentioned above is adopted, the sample should be place in the center of the chamber.
  3. Environment Condition
    Test should not be affected by other light sources except for the defined one. It is ideal to test in dark condition.
  4. Requirements for Switching The Light Sources
    Switch instantly without any delay.
  5. Equipped with various kinds of light sources
    Assess sample in different light sources
  6. Record Lamp Usage Time
    Once the lamp is used over 2000h or 1 year, it should be replaced.
